How To Install unixODBC-devel on CentOS 7 and Connect DB2 V9.7

Introduction

In this tutorial we learn how to install unixODBC-devel on CentOS 7.

What is unixODBC-devel

The unixODBC package can be used to access databases through ODBC drivers. If you want to develop programs that will access data through ODBC, you need to install this package. The unixODBC package can be used to access databases through ODBC drivers. If you want to develop programs that will access data through ODBC, you need to install this package.

We can use yum or dnf to install unixODBC-devel on CentOS 7. In this tutorial we discuss both methods but you only need to choose one of method to install unixODBC-devel.

Install unixODBC-devel on CentOS 7 Using yum

Update yum database with yum using the following command.

sudo yum makecache

After updating yum database, We can install unixODBC-devel using yum by running the following command:

sudo yum -y install unixODBC-devel

Install unixODBC-devel on CentOS 7 Using dnf

If you don’t have dnf installed you can install dnf first. Update yum database with dnf using the following command.

sudo dnf makecache

After updating yum database, We can install unixODBC-devel using dnf by running the following command:

sudo dnf -y install unixODBC-devel

How To Uninstall unixODBC-devel on CentOS 7

To uninstall only the unixODBC-devel package we can use the following command:

sudo dnf remove unixODBC-devel

unixODBC-devel Package Contents on CentOS 7

/usr/include/autotest.h
/usr/include/odbcinst.h
/usr/include/odbcinstext.h
/usr/include/sql.h
/usr/include/sqlext.h
/usr/include/sqltypes.h
/usr/include/sqlucode.h
/usr/include/unixodbc_conf.h
/usr/include/unixodbc_conf_i386.h
/usr/include/uodbc_extras.h
/usr/include/uodbc_stats.h
/usr/lib/libesoobS.so
/usr/lib/libmimerS.so
/usr/lib/libnn.so
/usr/lib/libodbccr.so
/usr/lib/libodbcdrvcfg1S.so
/usr/lib/libodbcdrvcfg2S.so
/usr/lib/libodbcminiS.so
/usr/lib/libodbcnnS.so
/usr/lib/libodbctxtS.so
/usr/lib/liboplodbcS.so
/usr/lib/liboraodbcS.so
/usr/lib/libsapdbS.so
/usr/lib/libtdsS.so
/usr/lib/libtemplate.so
/usr/include/autotest.h
/usr/include/odbcinst.h
/usr/include/odbcinstext.h
/usr/include/sql.h
/usr/include/sqlext.h
/usr/include/sqltypes.h
/usr/include/sqlucode.h
/usr/include/unixodbc_conf.h
/usr/include/unixodbc_conf_x86_64.h
/usr/include/uodbc_extras.h
/usr/include/uodbc_stats.h
/usr/lib64/libesoobS.so
/usr/lib64/libmimerS.so
/usr/lib64/libnn.so
/usr/lib64/libodbccr.so
/usr/lib64/libodbcdrvcfg1S.so
/usr/lib64/libodbcdrvcfg2S.so
/usr/lib64/libodbcminiS.so
/usr/lib64/libodbcnnS.so
/usr/lib64/libodbctxtS.so
/usr/lib64/liboplodbcS.so
/usr/lib64/liboraodbcS.so
/usr/lib64/libsapdbS.so
/usr/lib64/libtdsS.so
/usr/lib64/libtemplate.so

Check unixODBC-devel on CentOS 7

odbcinst -j

Add DB2 Config on /etc/odbcinst.ini

nano /etc/odbcinst.ini

/etc/odbcinst.ini content :

[PostgreSQL]
Description = ODBC for PostgreSQL
Driver = /usr/lib/psqlodbc.so
Setup = /usr/lib/libodbcpsqlS.so
Driver64 = /usr/lib64/psqlodbc.so
Setup64 = /usr/lib64/libodbcpsqlS.so
FileUsage = 1
[MySQL]
Description = ODBC for MySQL
Driver = /usr/lib/libmyodbc5.so
Setup = /usr/lib/libodbcmyS.so
Driver64 = /usr/lib64/libmyodbc5.so
Setup64 = /usr/lib64/libodbcmyS.so
FileUsage = 1
[ODBC]
Trace = yes
Tracefile = /tmp/odbc.log
[DB2]
Description = DB2 Driver
Driver = /opt/ibm/db2/V9.7/lib32/libdb2.so
Driver64 = /opt/ibm/db2/V9.7/lib64/libdb2o.so
FileUsage = 1

Setting DB2 Connection For ODBC

nano /etc/odbc.ini

/etc/odbc.ini content :

[ODBC Data Sources]
dbschema = dbschema
[dbschema]
Description = Sample1
Driver = /opt/ibm/db2/V9.7/lib64/libdb2o.so
System = 127.0.0.1
UserID = username
Password = password
Port = 50000
Naming = 1
DefaultLibraries = QGPL
Database = DATABASE
ConnectionType = 0
CommitMode = 2
ExtendedDynamic = 0
DefaultPkgLibrary = QGPL
DefaultPackage = A/DEFAULT(IBM),2,0,1,0,512
AllowDataCompression = 1
LibraryView = 0
AllowUnsupportedChar = 0
ForceTranslation = 0
Trace = 0

Testing DB2 Odbc Connection :

isql -V dbschema

TroubleShooting :

IF ODBC DB2 connection not connect please http/PHP SELINUX FOR ODBC ALLOW:

setsebool -P httpd_can_network_connect=1

IF ODBC DB2 connection not connect cause permission please SeLinux ALLOW/pause :

setenforce 0

IF ODBC DB2 Driver issue Error Please Allow Path :

chcon -R -t httpd_sys_rw_content_t storagechcon -R -t httpd_sys_rw_content_t /pathchcon -R -t httpd_sys_rw_content_t /opt/ibm/db2/V9.7/lib32/libdb2.so

--

--
